15KHz fully automatic automobile bumper ultrasonic welding machine, robot linkage production line

Place of Origin:Dongguan Guangdong

Brand Name:LINJIE

Certification:CE, ISO9001

Minimum Order Quantity:1 set

Packaging Details:Standard import and export wooden crates

Delivery Time:15 days

Payment Terms:50% T/T, 70% L/C

Applicable Industries: Hotels, GarmentShops, Building Material Shops etc.

Welding material:ABS PP PC PE etc.

Features of the entire machine:

1. Manual precision limit fine adjustment, high precision.

2. Manual precision limit fine adjustment, high accuracy, up to 0.02mm.

3. Linear ball guide rails, high precision and long service life.

4. The bottom plate is adjustable, making mold adjustment easily.

5. The digital machine interface can be switched between Chinese and English, which is intelligent and efficient.

6. The power of the machine can be adjusted arbitrarily.

7. Taiwan original transformer ceramic converter, stable and durable.

8. Titanium alloy transformer, low repair rate.

9. Frequency modulation and automatic frequency compensation circuit.

Device configuration parameters：

Model	LJ-2018C	LJ-2026C	LJ-2030C	LJ-1528C	LJ-1535C
Frequency	20KHz	20KHz	20KHz	15KHz	15KHz
Input Voltage	AC SINGLE PHASE,220V
MAX Input Power	1.8KW	2.6KW	3.0KW	2.8KW	3.5KW
Horn Journey	75/100MM
Oscillating System	Line
Output Mode	Time/Energy/External Control/Grounding
Pressure	Pressure bound 1-7bar
Welding Capability	Ø80	Ø100	Ø150	Ø170	Ø190
Compressor	1HP-2HP
Dimension	8105501300MM
N.W	60KG	60KG	62KG	65KG	68KG
